Spare modules
FLP-12,5-VBH/0
Order number: A07050
- replacement module for FLP-(EV)12,5-VBH/x
Technical parameters
| Parameter name | Parameter value | |
|---|---|---|
| Type of SPD | T1,T2 | |
| Maximum operating voltage | Uc | 275.00 V AC |
| Short-circuit current rating | ISCCR | 50.0 kA |
| Lightning impulse current (10/350 µs) | Iimp | 12.50 kA |
| Nominal discharge current (8/20 µs) | In | 30.00 kA |
| Maximum discharge current (8/20 µs) | Imax | 60.00 kA |
| Test voltage | Uoc | 10.0 kV |
| Voltage protection level | Up | 1.50 kV |
| Response time | ta | 100 ns |
| Fault indication | red indication field | |
| Customs tariff number | 85363030 | |
| EAN | 8595090570509 |
Files for download
-
Product dimensions
-
Basic circuit diagram
