ISG-100H Ex

ISG-100H Ex

Describe first line
two M8 bolts with nuts, stainless steel enclosure
Product description
  • heavy duty encapsulated isolating spark gap for use in Hazardous (Ex) Areas II2G Ex mb IIC T6 Gb and II2D Ex tb IIIC T80 °C Db
  • for indirect connection (earthing) of isolated conductive parts under lightning conditions
  • for safe installation in Ex zone 1 (gas) or 21 (dust)
Ordering number
A04132
Dimension drawing
Basic circuit diagram
Technical specifications
Classification
class H - heavy duty
Isolation resistance
100,00
MOhm
Lightning impulse current
Iimp
100,00
kA
Rated impulse sparkover voltage
Uimp
0,95
kV
Rated power frequency withstand voltage
UWAC
0,070
kV
Rated DC withstand voltage
UWDC
0,100
kV
Degree of protection
IP 67
Range of ambient temperatures (min/max)
-40 / 50 °C
According to standard
EN 62561-3, EN 60079-0, EN 60079-18, EN 60079-31
Explosion-tested version
II 2G Ex mb IIC T6 Gb, II 2D Ex tb IIIC T80°C Db
ETIM Class
EC000510
Customs tariff number
85363090
EAN
8595090541325
