Spare modules

FLP-NPE-25-VH/0

Order number: A07066

Technical parameters

Parameter name		Parameter value
Type of SPD		T1,T2
Maximum operating voltage	U_c	255.00 V AC
Lightning impulse current (10/350 µs)	I_imp	25.00 kA
Nominal discharge current (8/20 µs)	I_n	30.00 kA
Maximum discharge current (8/20 µs)	I_max	60.00 kA
Voltage protection level	U_p	1.50 kV
Ability to independently switch off the following current	I_fi	0.1 kA
Response time	t_a	100 ns
ETIM Class		EC000941
Customs tariff number		85363030
EAN		8595090570660
